It supports mouse drag. Take setting up motion detection area for example: Click customized,
hold down the left button and drag to set motion detection area.
In Playback:
Click to choose the options. Right click to return to live mode.
In Backup:
Click to choose the options. Right click to return to previous picture.
In PTZ Control:
Click left button to choose the buttons to control the PTZ. Click right button to return to live.
Note: Mouse is the default tool for all operations unless an exception, as indicated.
3
Basic Function Instruction
3.1 Power On/Off
Before you power on the unit, please make sure all the connection is good.
3.1.1 Power On
①
Connect with the power.
②
The device will boot and the power LED would turn blue.
③
A WIZARD window will pop up and show some information about time zone, time setup,
network configuration, record configuration and disk management. User can set up here
and refer to the concrete setup steps from the corresponding chapters. If users don't
want to set up Wizard, please click Exit button to exit. Press and hold FN/ESC key to
switch the resolution of VGA and HDMI output.
