Audio: Enable sound.
PTZ: Click the PTZ button to control rotation position, speed and auto scan of the PTZ.
Snap: Click this button to snap the live pictures. These pictures will automatically be saved in the
SATA disk.
Record: Click this button to start/stop recording.
Playback: Click this button to playback the record files. Click the
icon to select playback time. For example, if 2 minutes is selected and then click playback button,
it will start to play from 2 minutes ago.
User can click button and drag it anywhere with the left mouse.
Click Menu button to pop up a window as Fig 4‐2. You can also press MENU button on
the front panel or operate with remote controller to display the main menu. Clicking Setup icon
will pop‐up the configuration menu:
*Notice: IP Camera setup is available only in version 3.4.3 and higher and not
supported by SA‐4100AHD‐1 (MM)
AHD DVR User Manual
Fig 4‐2 Setup
13
icon beside the playback
