Provision ISR IPSeries User Manual page 12

Nam
Item
e
1 Power Button
2 DVD button
3 Keys 0‐9
4 (0/—)
5 Audio/+
6 P.T.Z./ ‐
Input button
7
Work state indicator
8
Function button
9
Jog
10
11 USB
12 IR receiver
13 External IR
AHD DVR User Manual
Soft switch off to stop firmware running. Do it before power off.
Press this button, user can place the DVD to do backup.
Input number 1‐9 or choose camera
1. Represents channel number. 2. Indicates digital number 0
1. Control voice 2. Increase the value in setup
1. Enter PTZ mode in live 2. Decrease the value in setup
Direction button Change direction to select items
Multi‐screen Change screen display mode like1/4/9/16 channel
Enter button Confirm selection
REC When recording, the light is blue
HDD When HDD is writing and reading , the light is blue
Backup When backup files and data, the light is blue
Net When access to network , the light is blue
Play When playing video, the light is blue
Power Power indicator, when connection , the light is blue
MENU Enter menu in live
INFO Check data, same as: Main menu=>Information
BACKUP Enter backup mode in live
Enter search mode
SEARCH
REW Rewind
Fast forward
FF
REC Record manually
Play/Pause
PLAY
STOP Stop/Esc
Control rewind/fast forward/frame when playing the image.
external USB devices (USB flash, USB HDD for backup, update firmware, USB mouse)
IR Remote controller receiver
EXT_IR Extension for the IR receiver
