1. Connect the DVR to internet through router or virtual server.
①
The network setups are the same as step one to step four of point 1 on WAN of IE remote
surveillance.
②
Enter WAN IP and HTTP port in the Safari browser to install the Active control. The
concrete steps are the same as step 5 and 6 of Chapter 7.3.1.
2. Connect the DVR to internet directly.
①
The network setups are the same as step one of point 2 on WAN of IE remote surveillance.
②
Enter WAN IP and HTTP port in the Safari browser to install the Active control. The
concrete steps are the same as step 5 and 6 of Chapter 7.3.1.
8.4 The Remote Live Preview
1 Channel indicator
3 Volume
5 Snapping picture
7 Start IE record
9 Master/sub
status
11 PTZ control
Note: Click
AHD DVR User Manual
Fig 7‐1 Remote Live Preview Interface
2 Screen display mode
4 Start recording
6 Bidirectional talk
8 Playback
stream 10 Color
button to start recording. The record file will be saved in user's PC.
