②
In the preset setting tab, enable preset, set the preset name and then click preset
"Setting" button.
③
Control the dome by rotating up, up left, down, right down, left, left down, right and up
right and adjust the rotate speed and the value of zoom, focus and iris of the dome.
Note: PTZ must support wiper and light button and these two buttons are just available
when selecting PELCOP or PELCOD.
④
Select the serial number of the preset point. Click
and click button to enable the PTZ light.
⑤
Click "Save" button to save the setting. Click
view this bar again. Click
⑥
Return to the Advanced‐Preset Setting interface and click OK button to save the setting.
To set up cruise:
①
In the Advanced interface, click cruise "Setting" button to see a window.
AHD DVR User Manual
Fig 4‐34 Advanced‐Preset Setting
Fig 4‐35 Preset Setting
button to enable the PTZ wiper
icon to hide the tool bar. Right click to
icon to exit the current interface.
