and time (day or night), you can adjust its value according to the practical conditions. Left
click the grid and drag to delete area. Click
area. Click icon to clear the set detection area. Click
as per the local conditions. Once motion is sensed, it displays a figure icon. Click
icon, to save the setting. Click
Note: Prior to setting motion detection field it is recommended that you click
to clear the existing field and set afresh.
⑧
Select "All" to set the same settings for all channels.
⑨
Click "Apply" button to save the setting.
⑩
Go to Schedule tab. The setting steps for schedule for motion based alarm are similar to
normal schedule setup (see Chapter 4.4.1 for more details).
5.5.2 Video Loss
This DVR can be set up to detect video loss. The setting steps are as follows:
①
Go to Main MenuSetupAlarm Video Loss. Refer to Fig 4‐20.
②
The setup steps of video loss trigger are similar to motion trigger setting. (See Chapter
4.5.1 MotionTrigger setting for more details).
5.5.3 Other Alarm
This tab gives a choice to configure alarm for Disk Full, IP Conflict, the Disconnect event, Disk
Attenuation or Disk Lost.
①
Go to Main MenuSetupAlarmOther Alarm. Refer to Fig 4‐21.
②
Use the dropdown menu and select the event or the alarm.
③
Check the required trigger options.
④
If the selected event is "Disk Full", then use the drop down box for "Disk Shortage Alarm"
to choose a threshold value for remaining HDD space. If the threshold value is reached,
AHD DVR User Manual
icon to set the whole area as detection
icon to exit the current interface.
Fig 4‐20 Alarm Configuration‐Video Loss
25
icon to test the sensitivity
icon
