2.3 Remote Controller
It uses two AAA size batteries.
① Open the battery cover of the remote controller.
② Place batteries. Please take care the polarity (+ and ‐).
③ Replace the battery cover.
The interface of remote controller is shown below.
2.4 Control with Mouse
2.4.1 Connect Mouse
It supports USB mouse through the ports on the rear panel.
If mouse is not detected or doesn't work, check below steps:
1. Make sure the mouse is plugged in the USB mouse port.
2. Try with a good know mouse.
2.4.2 Use Mouse
During live:
Double‐click on any camera window to see the full screen. Double‐click again to return to the
previous screen.
Right click to reveal the control menu on the screen. Right click again to hide the menu.
In Configuration:
Click to enter a particular option. Right click to cancel the option or to return to the previous
menu.
In order to input a value in a particular screen, move cursor to the input box and click. An input
window will appear as below. It supports digits, alphabets and symbols input. Click "Shift"
button to input capital letters and symbols; click "Shift" button again to return.
AHD DVR User Manual
Button
REC Record manually.
Search To enter search mode.
MEUN To enter menu.
Exit To exit the current interface.
ENTER To confirm the choice or setup.
Direction
To move cursor in setup.
button
ZOOM To zoom in.
PIP To set picture in picture.
To control playback. Play/Pause/Stop/Previous
Section/Next Section/Rewind/Fast Forward.
Multi To choose multi screen display mode.
Next To switch between single picture and picture group.
SEQ To enter auto dwell mode.
Get information about DVR like firmware version,
INFO
HDD information.
7
Function
