Disassembly

Disassembly Steps

The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
2 - 4 Disassembly Steps
To remove the hard disk drive assembly:
1.Remove the battery
2.Remove the hard disk drive assembly
To remove the keyboard:
1.Remove the battery
2.Remove the keyboard
To remove the system memory:
1.Remove the battery
2.Remove the keyboard
3.Remove the system memory
To remove the CD Device:
1.Remove the battery
2.Remove the CD Device
To remove the CPU:
1.Remove the battery
2.Remove the CPU
page 2 - 9
page 2 - 10
page 2 - 9
page 2 - 11
page 2 - 9
page 2 - 11
page 2 - 12
page 2 - 9
page 2 - 13
page 2 - 9
page 2 - 14
