Disassembly

Remove the Top Case and LCD

Figure 2 - 8
Top Case and
1. Refer to page 2 - 5 to make sure you have removed all the necessary components.
LCD Removal
2. Turn the computer over and remove the screws 1-11 ( Figure 2 - 8a ) from the bottom of the case.
Sequence
3. Turn the computer back over and remove the screws 12-16 ( Figure 2 - 8b ) from the top of the case.
a. Remove the screws
4. Disconnect the 2 speaker cables from audio sockets 19 ( Figure 2 - 8b ), and disconnect the ribbon cable 18 ( Figure
from the bottom of
2 - 8b ) connecting the LED cover module and board..
the case.
b. Remove the screws
a.
from the top of the
case, disconnect the
1
speaker cables and
LED cover module
cable.
11
10
9
• 17 Screws
2 - 16 Remove the Top Case and LCD
2 3 4
8
5
b.
6
14 15
13
7
12
16
18
17
19
