External Locator - Left & Right Side Views
Figure 1 - 2
Left View
1. CD or DVD Label
Indicator
2. Busy Indicator
3. Open Button
4. Emergency Eject
Hole
Figure 1 - 3
Right View
1. Microphone-In
Jack
2. Speaker-Out
Jack
3. S/PDIF Port
4. Sony Memory
Stick Port
5. Secure Digital
Port
6. Floppy Disk Drive
7. Floppy Disk Eject
Switch
8. Dual PC Card
Slots
9. PC Card Socket
Eject Buttons
10.IEE 1394 Port
11.Dual USB Ports
12.Vent
