EUROCOM 4200 Service Manual page 30

Disassembly
2 - 6 Disassembly Steps
To remove the floppy disk drive assembly:
1.Remove the battery
2.Remove the CD Device
3.Remove the hard disk drive assembly
4.Remove the keyboard
5.Remove the system memory
6.Remove the CPU
7.Remove the top case and LCD
8.Remove the floppy disk drive
To remove the audio board:
1.Remove the battery
2.Remove the CD Device
3.Remove the hard disk drive assembly
4.Remove the keyboard
5.Remove the system memory
6.Remove the CPU
7.Remove the top case and LCD
8.Remove the floppy disk drive
9.Remove the bottom case and audio board
page 2 - 9
page 2 - 13
page 2 - 10
page 2 - 11
page 2 - 12
page 2 - 14
page 2 - 16
page 2 - 19
page 2 - 9
page 2 - 13
page 2 - 10
page 2 - 11
page 2 - 12
page 2 - 14
page 2 - 16
page 2 - 19
page 2 - 20
