Disassembly

Disassembly Steps

The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the Battery:
1. Remove the battery
To remove the CMOS Battery:
1. Remove the battery
2. Remove the CMOS battery
To remove the HDD:
1. Remove the battery
2. Remove the HDD
To remove and install a Processor:
1. Remove the battery
2. Remove the processor
3. Install the processor
To remove the System Memory:
1. Remove the battery
2. Remove the system memory
To remove the Wireless LAN Module:
1. Remove the battery
2. Remove the wireless LAN
2 - 4 Disassembly Steps
All manuals and user guides at all-guides.com
page 2 - 5
page 2 - 5
page 2 - 6
page 2 - 5
page 2 - 7
page 2 - 5
page 2 - 9
page 2 - 11
page 2 - 5
page 2 - 12
page 2 - 5
page 2 - 14
To remove the Keyboard:
1. Remove the battery
2. Remove the keyboard
page 2 - 5
page 2 - 15
