EUROCOM 4200 Service Manual page 31

To remove the fan unit:
1.Remove the battery
2.Remove the CD Device
3.Remove the hard disk drive assembly
4.Remove the keyboard
5.Remove the system memory
6.Remove the CPU
7.Remove the top case and LCD
8.Remove the floppy disk drive
9.Remove the bottom case
10.Remove the fan unit
To remove the PCMCIA assembly:
1.Remove the battery
2.Remove the CD Device
3.Remove the hard disk drive assembly
4.Remove the keyboard
5.Remove the system memory
6.Remove the CPU
7.Remove the top case and LCD
8.Remove the floppy disk drive
9.Remove the bottom case
10.Remove the fan unit
11.Remove the PCMCIA assembly
