Disassembly

Disassembly Steps

The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the Battery:
1. Remove the battery
To remove the HDD:
1. Remove the battery
2. Remove the HDD
To remove the Optical Device:
1. Remove the battery
2. Remove the Optical device
To remove the Keyboard:
1. Remove the battery
2. Remove the keyboard
To remove the System Memory:
1. Remove the battery
2. Remove the system memory
To remove the M.2 SSD:
1. Remove the battery
2. Remove the SSD
To remove the Wireless LAN Module:
1. Remove the battery
2. Remove the WLAN
2 - 4 Disassembly Steps
To remove the 3G Module:
page 2 - 5 1. Remove the battery
2. Remove the 3G
page 2 - 5
page 2 - 6
page 2 - 5
page 2 - 10
page 2 - 5
page 2 - 11
page 2 - 5
page 2 - 12
page 2 - 5
page 2 - 13
page 2 - 5
page 2 - 14
page 2 - 5
page 2 - 16
