Remove The Power Board - EUROCOM 4200 Service Manual

Disassembly

Remove the Power Board

Figure 2 - 16
Power Board
1. Remove the hex studs 1-4 ( Figure 2 - 16a ) from the IO bracket, and separate the IO bracket from the mainboard
Removal
slightly.
Sequence
2. Release connector 5 ( Figure 2 - 16b ) from the fan to the mainboard (top) at point 6 .
a. Remove the hex
3. Turn the board over to the underside and remove screws 8-10 ( Figure 2 - 16c ) from the power board, and release
studs from the IO
the connector at point 11 ( Figure 2 - 16c ) to the IO bracket.
bracket.
b. Release the con- 4. Lift the power board up and away from the mainboard.
nector from the fan
5. With all the procedures complete you will be left with the mainboard.
to the mainboard.
c. Remove the screws
from the power
a.
board.
d. Lift the power board
up and away from
the mainboard.
c.
7. IO bracket
11. Power board
• 4 Hex Studs
• 3 Screws
2 - 22 Remove the Power Board
1 2 3
11
9
8
4
b.
7
d.
10
5
6
