Disassembly

Disassembly Steps

The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the Battery:
1. Remove the battery
To remove and install the HDD:
1. Remove the battery
2. Remove the HDD
3. Install the HDD
To remove the Optical Device:
1. Remove the battery
2. Remove the Optical device
To remove the Primary System Memory:
1. Remove the battery
2. Remove the system memory
To remove the System Memory under the
Keyboard:
1. Remove the battery
2. Remove the keyboard
3. Remove the system memory
To remove and install the Processor:
1. Remove the battery
2. Remove the system memory
3. Remove the processor
4. Install the processor
2 - 4 Disassembly Steps
To remove the WLAN Module:
1. Remove the battery
page 2 - 5
2. Remove the keyboard
3. Remove the wireless LAN
page 2 - 5
To remove the 3G:
page 2 - 6
page 2 - 8 1. Remove the battery
2. Remove the 3G
To remove and install the Video Card:
page 2 - 5
page 2 - 9 1. Remove the battery
2. Remove the video card
3. Install the video card
page 2 - 5
page 2 - 12
page 2 - 5
page 2 - 10
page 2 - 13
page 2 - 5
page 2 - 10
page 2 - 14
page 2 - 16
page 2 - 5
page 2 - 10
page 2 - 17
page 2 - 5
page 2 - 18
page 2 - 5
page 2 - 19
page 2 - 20
