EUROCOM 4200 Service Manual page 29

To remove the modem:
1.Remove the battery
2.Remove the keyboard
3.Remove the modem
To remove the Top Case and LCD:
1.Remove the battery
2.Remove the CD Device
3.Remove the hard disk drive assembly
4.Remove the keyboard
5.Remove the system memory
6.Remove the CPU
7.Remove the top case and LCD
To remove the Inverter:
1.Remove the battery
2.Remove the CD Device
3.Remove the hard disk drive assembly
4.Remove the keyboard
5.Remove the system memory
6.Remove the CPU
7.Remove the top case and LCD
8.Remove the inverter
page 2 - 9
page 2 - 11
page 2 - 15
page 2 - 9
page 2 - 13
page 2 - 10
page 2 - 11
page 2 - 12
page 2 - 14
page 2 - 16
page 2 - 9
page 2 - 13
page 2 - 10
page 2 - 11
page 2 - 12
page 2 - 14
page 2 - 16
page 2 - 18
Disassembly
Modem Cable
The procedure de-
scribed here is suffi-
cient to enable the
removal of the modem
module itself.
If the modem cable
also needs to be re-
moved, or a new mo-
dem module and cable
inserted, then the top
case must also be re-
moved to access the
cable connector.
See "To remove the
Top Case and LCD:"
on page 2 - 5.
Disassembly Steps 2 - 5
