4. Hardware Installation
Menu Orientation
and RESET, same with DVI1.
Note
Only comments to professional operator .
MENU---TEXT OVERLAY
It can adjust the Text overlay function settings including as follows:
TEXT OVERLAY: Can select ― ON‖ or ― OFF‖, OFF is the default setting.
PRESET: Can preset value of the following functions, and total 13 modes:
User: User mode.
WhOnBk1: White On Black 1.
WhOnBk2: White On Black 2.
BkOnWh1: Black On White 1.
BkOnWh2: Black On White 2.
GrnOnBk1: Green On Black 1.
GrnOnBk2: Green On Black 2.
GrnOnWh1: Green On White 1.
GrnOnWh2: Green On White 2.
RedOnBk1: Red On Black 1.
RedOnBk2: Red On Black 2.
RedOnWh1: Red On White 1.
RedOnWh2: Red On White 2.
BLEND MODE: Blend mode, with two modes, ― Mode 1‖ and ― Mode 2‖.
Mode 1: Graphic content locate at the top and is non-transparent,
background transparency is controlled by double-image transparency;
Mode 2: Graphic content is controlled by double-image transparency, the
background is completely transparent;
BLEND LEVEL: Can set the image display transparency, regulating range
between 0 - 16;
VSP 198CVS User Manual 45
