5. Communication Software Guideline
Software Installation
Software Operation
Install communication which comes with the package of VSP 198CVS
device. Double click
Double click
software.
VSP 198CVS communication software interface as shown:
Connection
When control video processor through PC software, besides the power
cord, the product default equip with a line that is COM (RS-232), 9-pin
(DB9F), RJ11 COM crystal head (6 B4C). Below are the details about
connection of steps:
First connect 9-pin (DB9F) to the computer on the corresponding port, and
connect COM crystal to RS232 port on video processor. Open video
processor; Next, operate the computer, back to computer desktop, right
click 【My computer】 to 【Properties】 , find the 【Hardware】 option card,
VSP 198CVS
icon from home screen to run the software.
icon, then choose and double click to run the
User Manual
60
