1. Introduction

System Overview

System Overview
The VSP 198CVS is a multiple outputs video processor that accepts a
wide variety of video signals, including RGB computer graphic by DVI,
VGA, Standard and HDTV video by HDMI, Composite, SDI (SD/HD/3G
Compatible) .DVI and SDI supports loop through output for cascade or
preview. VSP 198CVS combines truly seamless, fade in fade out,
glitch-free switching with advanced scaling technologies to meet the
requirements of high quality, high resolution video presentations. VSP
198S also launches the latest user defined image size and coordinate,
dual image processing, multiple cascade mapping, different user
configurations and controlling, Key in and out and other advanced
functions for high-end show.
Multiple inputs
• VSP 198CVS provides 2x Composite (CVBS), 1x DVI (compatible with
HDMI 1.3), 1x HDMI,2xVGA, 1 x 3G self-adaptive SDI input (3G SDI
module), for the application if different signal inputs.
Multiple outputs:
• 1 x Preview VGA output
• 2 X DVI outputs are provided for splitting into two different images or
distributing the same two images, the two DVI outputs can be connected
with LED display or other display.
Loop through Interface
• Designed to boost the signal strength
• The same video can be connected to a local monitor
• The same video available for other equipment.
Multiple Control Methods
• Local Front Panel, remote Windows based software control by RS232、
USB, Ethernet.
VSP 198CVS
Features:
