6. System Setup and Operation
How to Realize the Screen Size and Full Size Switching
How to Scale the Screen Size and Full
Size Switching
VSP 198CVS supports the screen parameters to meet the requirement
where user want to switch between scale screen size and full display size
(like monitor). This is only enable for a single display window. Following is
an example of a screen size is 1408 x 832.
Operator can define the VSP 198CVS output resolution from standard
output resolution list or customized the output resolution which is higher
than 1408 x 832. For this application 1440x900 is an example：
Push [MENU] button to go into the main menu, and turn Knob goes to
<SCREEN PARAMETERS ， push Knob and goes into the <SCREEN
PARAMETERS > menu as following：
H SIZE—horizontal pixels, turn Knob and use the digital button to input the
value 1408；
V SIZE-- horizontal pixels, turn Knob and use the digital button to input the
value 832；
H POS—horizontal position, default value is 0, set the value as the way
HSIZE and VSIZE；
V POS--vertical position, default value is 0, set the value as the way HSIZE
and VSIZE；
VSP 198CVS User Manual 96
