6. System Setup and Operation

How to Set up image zoom

How to Set up image zoom
The image can be zoom in horizontal or vertical separately, to meet the
special effects required.
Push [MENU] button to go into the main menu, and turn Knob goes to
ZOOM menu and push Knob to confirm to go inside ZOOM menu as
following：
V UP—Zoom in vertical and the image will be zoom in to the top
direction from its bottom part；
V DOWN-- Zoom in vertical and the image will be zoom in to the down
direction from its top part；
V UP/DOWN—Zoom in vertical but in both top and down direction
from its middle part；
H LEFT-- Zoom in horizontal and the image will be zoom in to the left
direction from its right part；
H RIGHT--Zoom in horizontal and the image will be zoom in to the
right direction from its left part；
H LIFT/RIGHT--Zoom in horizontal but in both left and right direction
from its middle part；
CENTER—Zoom in 4 corner direction from center.
