4. Hardware Installation
Menu Orientation
VSP 198CVS
gamma value; Gamma values include: LINEAR, sRGB, -1.2,
-1.4, -1.6, 1.2, 1.4, 1.6;
ASPECT RATIO:change the value to convert the aspect
ratio for different wide and height ratio settings.
Normal: Original video ratio, 4:3 aspect ratio; 16:9 aspect
ratio;
Note
The RATIO button can also active this setting.
OUTPUT ADJUST: Output adjust menu, the sub-menu as
following:
DVI1, setting as following:
DVI MODE: Can set the protocol as HDMI or DVI; default is
DVI output, HDMI signal output will enable when HDMI
option checked.
DATE RANGE: DVI1 output range can set as RGB (graphic
mode) or YCbCr (video mode); RGB output scale range is
between 0-255, YCbCr range from 16 to 235.
DE ADJUST: DE adjust, the sub-menu as following:
DE ON/OFF: Can choose to open or close, when choose
open, it can be adjusted to DE, as follows:
H SIZE: Width setting;
V SIZE: Height setting;
H Pos: Horizontal phase setting;
V Pos: Vertical phase setting;
When the signal source of the screen appear black side, can
use this function to shift the black out of the screen.
RESET: If image distorts as improper operation, it can be
initialized to recover by factory reset.
DVI2: Including DVI MODE, DATA RANGE, DE ADJUST,
User Manual
44
