4. Hardware Installation
Menu Orientation
Image quality settings
VSP 198CVS
VGA2 SIGNAL TYPE：
Program VGA2 button is VGA signal or YPbPr signal;
VGA1 ADJUST：
Adjust VGA1 input signal ,sub menu as follows:
H POS:image horizontal position;
V POS:image vertical position;
CLOCK:input signal clock;
PHASE:input image phase;
Note
Only comments to professional operator .
AUTO ADJUST: auto adjust VGA1 input signal H POS,
V POS,CLOCK, PHASE; auto adjust to display in full screen
image.
Note
Comments customers to use this operation in
adjusting the VGA input shiftment.
SDI/HDMI/VGA2 ADJUST：
When SDI/HDMI/VGA2 input signal image shift ,please
adjust image's H POS and V POS, to display in full screen
image.
sub menu as follows:
H POS: image horizontal position;
V POS: image vertical position;
RESET:Restore the factory Settings
ADC ADJUST:
Mainly aim at the BRIGHTNESS to auto adjusting.
GAMMA: Gamma setting, press it to adjust the image
