2. Hardware Orientation
VSP 198CVSFront Panel

VSP 198CVS Front Panel

Insert power cord and push power to ON position. OLED module on the
front panel will show RGBLINK and go into its self verification before it load
last setting config and send processed image to the target monitor. For the
first setup, CV1 input is the default source. With front panel keyboard, user
can operate VSP 198CVS through the menus on OLED module.
VSP 198CVS front panel as shown in figure:
INPUT
SV: 1.30
OUTPUT FORMAT
VSP 198CVS
亮彩系列
AVDSP Series VSP 198CVS
CV1:480I
SN:0016
F V2 A V1
: 1920X1080X60Hz
User Manual
V1 V1 V1
