4. Menu Orientation
QUICK MENU
PIP setting, choose PIP and choose ON to set PIP mode.
LAYOUT: Thera are 7 pip layouts,Can choose PIP layouts anyone, the
corresponding results are as follows;
PIP L+T
SELECT: Can choose to set the size or position of IMAGE A or IMAGE B
individually;
SWAP IMAGE: It can set PIP to swap exchange, when choose ON, it can
realize the main and sub-image exchange.
ALPHA: Can set the image display transparency, regulating range between
0 - 16;
Details please refer to the instructions in the
PIP .
QUICK MENU—SPLIT FUNCTION
Press the SPLIT button ,button led light turn on ,enter the SPLIT function
menu.touch the knob and turn the knob,open split function ,OLED screen as
follows:
VSP 198CVS
PBP L+R
Note
Function reuse kye
A or image B
—>SPLIT
H TOTAL
H TOTAL
H POS
User Manual
PBP T+B
SPLIT
6
,selecting image
manual：How to Set up the
ON
1920
1080
0
