RGBlink VSP 198CVS User Manual page 117

HDMI Input
Number of Inputs
Connector
Supported Resolution
Signal Level
Format Standard
CVBS Input(CV module)
Number of Inputs
Connector
Supported Standards
Signal Level
Multiplex
VGA Input(CV module)
Number of Inputs
Connector
Supported Standard
Signal Level
Supported Resolution
SDI Input(3G module)
Number of Inputs
Connector
Transmission speed
Supported Standard
Balance
Signal Level
SDI Loop-through (3G module)
Number of
Loop-through
Connector
Signal Level
Supported Resolution
VSP 198CVS
1
Standard HDMI-A socket
SMPTE：625/25/50 PAL, 525/29.97/59.94 NTSC,
1080P50,1080P59.94/60,1080i50,1080i59.94/60,
720p50,720p59.94/60
VESA：800×600×60Hz,1024×768×60Hz,1280×768×60Hz,
1280×1024×60Hz,1600×1200×60Hz,1920×1080×60Hz
TMDS pwl,single pixel input,165MHz bandwidth
HDMI 1.3
1
Standard BNC Socket
PAL/NTSC
1Vpp±3db (0.7V Video+0.3v Sync ) 75 ohm
480i,576i
1
Standard DB9 Socket
VGA-UXGA
R、 G、 B、 Hsync、 Vsync:0 to1Vpp±3dB (0.7V Video+0.3v Sync ) 75
ohm
black level：300mV Sync-tip：0V
VGA-UXGA (800*600@60, 1024*768@60, 1280*1024@60,
1440*900@60,1600*1200@60)
2
Standard BNC Socket
19.4Mbps~3Gbps
ITU-R BT.656,ITU-R BT.601,SMPTE 259M, SMPTE 292, SMPTE
297
Belden 1694A 100m
1.485G,350m self-adaptive 270Mbps
TMDS pwl , 165MHz bandwidth
1
Standard BNC Socket
800mV±10%
SMPTE：625/25 PAL, 525/29.97 NTSC,625/50p PAL,525/59.94p
NTSC,
720p50,720p59.94/60,1080i50,1080i59.94/60,1080p50,1080p59.
94/60,
User Manual
self-adaptive 3G,200m self-adaptive
117
