VSP 198CVSBack Panel

VSP 198CVS Back Panel

The figure below illustrates the professional interface and control signals of
VSP 198CVS back panel.
NO INTERFACE
1.3 CVBS Input
2.4 VGA Input
5 SDI Input
6 SDI Loop Out
7 Push button switch
8 10/100M Interface
9

USB Interface

10 RJ11(RS232) Interface

CONT Interface

7. Dial Switch

8. 10/100M UDP Interface

9. USB Interface
Remote communication control interface, used to connect to the computer
or console.

10. RS232 Interface

Used to connect the computer or console.
VSP 198CVS
NO
11.19 Sending card interface
12 Power Switch
13 HDMI Input
14 DVI Input
15 DVI Loop Out
16.17 DVI Output
18 VGA Output
20 Power interface
User Manual
INTERFACE
26
