2. Hardware Orientation
VSP 198CVSBack Panel

INPUT Interface

1) 2 CVBS inputs by BNC interfaces, (CV2 is CV module),
2) 2 VGA input by DB15 interface,(VGA2 is CV module)
3) 1 HDMI-A interface, can be compatible with HDMI inputs;
4) 1 DVI-I interface, can be compatible with HDMI, and supports loop
through output for cascade or preview;
5) 3G SDI input (SDI module), and supports loop through output for
cascade or preview.
3：CVBS Input
CVBS input: Can receive standard video signal from players, cameras etc.
Input supported resolution 480i and 576i via BNC. Supported standards
include: PAL, NTSC and SECAM.
4：VGA Input
VGA Interface: input the video signal from HD player and Computer, etc.
Compatible with YPbPr via the DB15 interface.
5：SDI Loop Out
SDI loop output: can connect the next level VSP 198CVS for cascade or
the device with SDI input.
6：SDI Input
Can receive video signal from HD player, and HD camera, connect
interface 16 via 75 ohm impedance BNC.
13：HDMI Input
HDMI input interface: Input the signal from HD player, DVD,
VSP 198CVS
Note
3 and 4 input interface is option CV module .
Note
5 and 6 input interface is option S module .
User Manual 27
