5. Communication Software Control Guide
How to Connect PC through LAN Interface?
Then press <Enter> button, the IP address (the red circle) will display on
the computer: 192.168.0.132 ;
The third step
: Equipment IP address :192.168.0.100；
Computer IP address :192.168.0.132；
The fourth step:
If so, the communication connection can be built by line CAT5.
Note
VSP 198CVS
the two IP address are in the same band, i.e.192.168.0.XXX,
the fourth section numbers (XXX) will not repeat previos.
If computer IP address and equipment IP
address are not in same band, For example, the
computer IP address is 218.032.010.201；We
need to revise the computer IP address to
192.168.0.xxx.
Open network connections, right click on
properties, Select Internet protocol (TCP/IP),then
Click properties,
