Area
❶ PREVIEW
❷ PROGRAM
HDMI Signal
❸
❹ UVC Signal
❺ Audio Status
❻ Recording
Streaming
❼

3.2 MENU

There is a 5.5" screen on operation board showing input& output status and menu content.
Push MENU Button in Main Interface and the LCD screen will quickly enter MENU.
As shown in the figure above, the UI style on thescreen is similar to current smart phone
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
Description
Show Preview screen and audio meter.
Show Program screen and audio meter.
Show HDMI 1~4 signals and audio meter.
View audio and video signals provided to live streaming software or video
conferencing software.
Monitor Microphone, UAC, Line-in and Bluetooth audio input status.
Check recording duration and remaining recording duration.
Check streaming duration and status.
