How to do customized output resolution

How to do customized output resolution
Push [MENU] button to open the main menu，turn Knob and go to
<OUTPUT FORMAT >，push Knob and confirm to go into the <OUTPUT
FORMAT > menu, as following：
STANDARD—standard resolution；
CUSTOMIZED—user defined resolution setting；
Push Knob and go into <CUSTOMIZED > menu：
turn knob on each bit position, and change the value of the bit by the digital
buttons on the front panel. For example, input 1536 as following；
After the digital push Knob will add * , means before * is the horizontal size.
Same operation for vertical size, for example input 1536 as following；
After the digital push Knob will add * , means before * is the vertical size.
Same operation by push digital buttons to set the refresh rate. For example
to input refresh rate 60.；
VSP 198CVS
自定义分辨率
*
自定义分辨率
1536*
自定义分辨率
1536*1536*
自定义分辨率
1536*1536*60Hz
