2. Hardware Orientation
VSP 198CVSFront Panel
SAVE
Save button :Push to enter SAVE mode, turn the knob to select save
position or push the user mode buttons which light up from 0~9 directly
Currently, it supports 10 saving modes, from 1，2，3，4，5，6，7，8，9，
0 means SAVE 1~10.
The OLED menu will show Finish after finish saving.
For details please refer to MENU
SAVE.
LOAD
LOAD button: Push to enter LOAD mode, turn the knob to select LOAD
position or push the user mode buttons which light up from 0~9 directly.
Currently, it supports 10 loading modes from: 1，2，3，4，5，6，7，8，9，
0 means LOAD user mode 1~10,
The OLED menu will show Finish after finish loading.
For details please refer to MENU
LOAD.
MENU
Advanced menu button : Push the MENU to enter the main menu. Turn the
knob to select the relevant submenu. For details please refer to
menu orientation.
ESC reuse function button: Push the MENU to exit the menu
Effect switch function: Push the MENU button two times to enter the
effect switch function menu.
VSP 198CVS
SPLIT reuse function :PIP mode,SPLIT button is
select image A or image B;
SAVE function
LOAD function
User Manual
and How to Set up the
and How to Set up the
MENU
