How to Set up the SPLIT

SPLIT is used when multiple VSP 198CVS are used in cascade mode. For
DVI input as mapping source, user can use DVI loop though to cascade two
pieces VSP 198CVS together and do the mapping for each of them, each
VSP 198CVS will support port of the display which connected by the
sending card or control system separately. For SDI input as mapping source,
user can use SDI loop though to cascade two pieces VSP 198CVS. For
other inputs, need to have the signal distributor before VSP 198CVS firstly,
and make sure each VSP 198CVS can receive the same timing signal after
the distributor.
Push the SPLIT button, the button led light will turn on ,enter the SPLIT
function menu. Push and Turn the knob will enable split function ,menu as
follows:
H TOTAL: LED screen Horizontal total size.
V TOTAL: LED screen Vertical total size.
H POS: this device display image Horizontal size
V POS: this device display image Vertical size.
H SIZE: this device display image Width setting.
V SIZE: this device display image Height setting.
RESET:Restore the factory Settings
Complete set every device, to save.
VSP 198CVS
—>SPLIT
H TOTAL
H TOTAL
H POS
V POS
H SIZE
V SIZE
RESET
User Manual
ON
1920
1080
0
0
1920
1080
