4. Hardware Installation
Menu Orientation
>>
—>ZOOM
SCALE >>
ZOOM：It can adjust the image zoom size and positions, settings including
as follows:
V UP--image to up zoom;
V DOWN--image to down zoom;
V UP/DOWN--image to up and down zoom ;
H LEFT--image to left zoom;
H RIGHT--image to right zoom;
H LIFT/RIGHT--image to left and right zoom;
CENTER--image from center to the edges zoom;
RESET: If image zoom setting goes to wrong as improper operation, it can
be initialized to recover by factory reset.
Details please refer to the instructions in the manual：How to Set up image
zoom.
SCALE：It can adjust the image scale size and image position settings
including as follows:
H SIZE: Width setting;
V SIZE: Height setting;
H Pos: Horizontal phase setting;
V Pos: Vertical phase setting;
RESET: If image quality distorts as improper operation, it can be initialized
to recover by factory reset.
NOTE
The SCALE button can also fulfill this setting.
Details please refer to the instructions in the manual：How to set up the Size
