6. System Setup and Operation

How to Realize the Text Overlay Setting

How to Realize the Text Overlay Setting
1. Press MENU button, rotate the knob,choose【TEXT OVERLAY】 and
enter【TEXT OVERLAY】, press the knob to confirm;
2. Rotate the knob, choose TEXT OVERLAY mode, choose ON, TEXT
OVERLAY function open;
3. Press MENU, return to 【TEXT OVERLAY】, rotate the knob, OLED
screen displays menu options, select 13 modes in PRESET, or select
BLEND, which includes two modes:
Mode 1: Graphic content locate at the top and is non-transparent,
background transparency is controlled by double-image transparency;
Mode 2: Graphic content is controlled by double-image transparency,
the background is completely transparent;
Rotate the knob and choose the mode;
4. Press MENU, return to【TEXT OVERLAY】, rotate the knob, choose
ABOVE/BELOW to select the layer position for IMAGE B;
5. Press MENU, return to【TEXT OVERLAY】, rotate the knob, choose
BLEND LEVEL, and set the image display transparency, regulating
range between 0 - 16;
6. Press MENU, return to【TEXT OVERLAY】, rotate the knob, choose the
color value:
RED: The value range of color RED that to be set, regulating range
VSP 198CVS
ADJUST
->TEXT OVERLAY
SYSTEM
LANGUAGE/语言
*TEXT OVERLAY
PRESET
BLEND MODE
BLEND LEVEL
User Manual
>>
>>
>>
ENG
ON
USER MODE
MODE1
0
99
