Installing a hot-swap power supply

This procedure applies only to server models that have hot-swap power supplies.
See "Installing a non-hot-swap power supply" on page 122 for information about the
installation of a non-hot-swap power supply.
To install a hot-swap power supply, complete the following steps.
Release lever
1. Place the power supply into the bay guides.
2. Using the handle, push the power supply toward the front of the chassis until it
3. Connect one end of the power cord into the connector on the back of the power
4. Make sure that both the ac and dc power LEDs on the rear of the power supply
100
System x3200 Types 4362 and 4363: Problem Determination and Service Guide
Hot-swap power
supply
locks into place.
supply and connect the other end of the power cord into a properly grounded
electrical outlet.
are lit, indicating that the power supply is operating correctly.
