IBM System x3200 Problem Determination And Service Manual page 87

Table 3. Parts listing, Types 4362 and 4363 (continued)
Index Description
9 Hard disk drive, SAS, 300 GB, 10 K, hot-swap, with tray
(optional)
9 Hard disk drive, SAS, 36 GB, 15 K, hot-swap, with tray
(optional)
9 Hard disk drive, SAS, 73 GB, 15 K, hot-swap, with tray
(optional)
9 Hard disk drive, SAS, 146 GB, 15 K, hot-swap, with tray
(optional)
9 Hard disk drive, SATA, 80 GB, hot-swap, with tray
(optional)
9 Hard disk drive, SATA, 160 GB, hot-swap, with tray
(optional)
9 Hard disk drive, SATA, 250 GB, hot-swap, with tray
(optional)
9 Hard disk drive, SATA, 500 GB, hot-swap, with tray
(optional)
10 Retention bracket, PCI
11 Hard disk drive cage, 3.5 in. drives
11 Hard disk drive cage, 2.5 in. drives
12 Hard disk drive backplane (for 2.5 in. and 3.5 in Hot-Swap
SAS/SATA hard disk drives)
12 Hard disk drive backplate (for 3.5 in. Simple-Swap SATA
hard disk drives)
13 Hard disk drive duct assembly (for part number 42C8910)
13 Hard disk drive duct assembly (for part number 42C8911)
14 System board assembly
15 SAS/SATA controller
16 Microprocessor, 800/1.87 GHz (models: 42x, 44x, 4Bx,
4Dx)
16 Microprocessor, 800/2.13 GHz (models: 52x, 54x, 56x,
5Dx, 5Bx, 5Fx)
16 Microprocessor, 800/2.4 GHz (models: 62x , 64x, 6Bx,
6Dx)
16 Microprocessor, 800/3.0 GHz
17 Fan sink
18 Side cover with lock
19 Power supply, non-redundant 400 watt (models 32x, 34x,
42x, 44x, 52x, 54x, 62x, 3Bx, 3Dx, 4Bx, 4Dx, 5Bx, 5Dx,
6Bx)
19 Power supply, redundant, 430 watt (optional)
20 Memory, 512 MB 533/667 MHz PC2-4200/5300 ECC
20 Memory, 1 GB 533/667 MHz PC2-4200/5300 ECC
(optional)
CRU part
number
(Tier 1)
39R7344
39R7346
39R7366
39R73422
39M4521
39M4525
39M4529
39M4517
42C8910
42C8911
25R8859
39Y7281
30R5151
41Y2728
Chapter 3. Parts listing, System x3200 Types 4362 and 4363
CRU part
number FRU part
(Tier 2) number
25R8790
39Y9757
25R8842
39Y9860
42C7507
41Y3852
42C1279
41Y3848
41Y3849
41Y3850
40K5454
43W0401
39Y7297
69
