Removing the SAS/SATA controller

To remove the SAS/SATA controller, complete the following steps.
1. Read the safety information that begins on page vii and "Installation guidelines"
2. Turn off the server and all attached devices; then, disconnect all power cords
3. Unlock and remove the side cover (see "Removing the side cover" on page 77).
4. Squeeze the tabs on both sides of the connector on the signal cable and
5. Carefully disengage the tabs on each side of the SAS/SATA controller connector
6. Grasp the edges of the SAS/SATA controller and pull it out of the connector. If
7. If you are instructed to return the SAS/SATA controller, follow all packaging
118
System x3200 Types 4362 and 4363: Problem Determination and Service Guide
on page 73.
and external cables.
remove the cable from the SAS/SATA controller.
and the front of the SAS/SATA controller from the plastic standoff.
the standoff comes away from the system board with the controller, gently pull it
out of the controller and push it back into the hole on the system board.
instructions, and use any packaging materials for shipping that are supplied to
you.
SAS controller
