10. Install and lock the side cover (see "Installing the side cover" on page 78).
11. Reconnect the external cables and power cords; then, turn on the attached

Removing a tape drive

To remove a tape drive, complete the following steps:
1. Read the safety information that begins on page vii and "Installation guidelines"
2. Turn off the server and peripheral devices, and disconnect the power cords and
3. Unlock and remove the side cover (see "Installing the side cover" on page 78).
4. Remove the upper bezel (see "Installing the upper bezel" on page 82).
5. Remove the lower bezel (see "Installing the lower bezel" on page 80).
6. Disconnect the power and signal cables from the drive that is to be removed.
7. Press and hold the blue release button on the side of the bay to release the
8. Remove the drive retainer clip from the side of the drive. Save the clip to use
9. If you are instructed to return the drive, follow all packaging instructions, and
90
System x3200 Types 4362 and 4363: Problem Determination and Service Guide
7. Connect the power and signal cables to the drive.
Note: Route the signal cable so that it does not block the airflow to the rear of
the drives or over the microprocessor and dual inline memory modules
(DIMMs).
8. Install the upper bezel (see "Installing the upper bezel" on page 82).
9. Install the lower bezel (see "Installing the lower bezel" on page 80).
devices and turn on the server.
Drive retainer clip
on page 73.
all external cables.
drive; then, pull the drive out of the front of the server.
when you install the replacement drive.
use any packaging materials for shipping that are supplied to you.
EMC shield
Filler panel
Tape drive
