The Selector Window: Hard Disk ToolKit• PE 's Main Screen
The main screen of Hard Disk ToolKit•PE is referred to as the Selector
window. Devices must be selected within it before any of HDT•PE's pri-
mary functions can be used.
All devices attached to all SCSI and IDE buses are listed in the Selector
window. If one or more SCSI accelerator boards are installed and have
SCSI devices connected to them, then these devices will also be displayed
in the Selector window. (HDT•PE supports other manufacturers' SCSI
accelerator boards, as long as they are SCSI Manager 4.3 compliant.)
Making a selection
Select a single device or volume by clicking on it once anywhere in the
row in which it appears. The currently selected device is highlighted in
the Selector window. A different drive/volume can then be selected by
using the keyboard's up and down arrow keys.
Selector window features
See Figure 3.2 and the accompanying tables for details on the Selector
window.
132
1 1 1 1
2 2 2 2
3 3 3 3
Figure 7.3: HDT•PE's Selector window. The numbered
items are explained in Table 1.
Hard Disk ToolKit• Personal Edition Reference Guide
4 4 4 4
5 5 5 5
