EP820 All-In-One EPIC Board User's Manual
Designed for the professional embedded developers, the Pentium
embedded board EP820 Series is virtually the ultimate one-step
solution for embedded system applications.
1.1

Specifications

CPU: Socket 478 for Intel
processors
System Chipset: Intel
BIOS
Phoenix-Award BIOS, Y2K compliant
4Mbit Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display
mode option and application extension features
RPL/PXE Ethernet Boot ROM
"Load Optimized Default" customized Setting in the BIOS
flash chip to prevent from CMOS battery fail
System Memory
One x 200-pin DDR2-400 SODIMM socket
Maximum to 1GB DDR2 memory
L2 Cache: integrated in CPU
Onboard IDE
2 channels up to 3 devices (1 parallel ATA-100 and serial
ATA-150)
PATA-100 as PIO Mode 0-4, DMA Mode 0-2 and Ultra
DMA-33/66/100
Onboard Serial ATA
Independent DMA operation
Data transfer rate up to 150 Mbyte/s
CompactFlash Socket
IDE1 support CompactFlash Type II Socket jumper
selectable as Master or Slave and DMA mode supported
2
® ®
Pentium M/ Celeron
®
915GM and ICH*6M
®
M
®
M
Introduction
