Power is 5V (Optional) or 3.3V (Defaulted)
Onboard Multi-I/O
One floppy (Optional) port supporting up to two devices
One SPP/EPP/ECP parallel port with 26-pin 2.0 pitch box-
header that supports LS-120
Two 16550 UART-compatible serial ports with +5V/+12V
power output in Pin 1 or Pin 9 via DIP jumper setting
1 x RS-232
1 x RS-232/422/485 and selectable via jumper setting and
auto flow control supported
DIO: 4bits input & 4bits output
USB Interface
Four USB ports with fuse protection and complies with
USB Spec. Rev. 2.0
Watchdog Timer
255 levels as SMI and Reset from 0 ~ 255 seconds
controlled by W83627HF
Bord Unique ID
Dallas DS2401 board unique ID supported for customized
application
Hardware Monitoring
Integrate Winbond W83627HF Super I/O
Monitoring for CPU/System temperatures, System Voltage
and CPU Fan speeds
Graphics/Streaming
VGA On-chip Intel
Supports up to 2048 x 1536 at 60 Hz resolution on non-
interlaced CRT monitors
Optional Dual LVDS LCD via Chrontel CH7308 converter
LCD backlight control supported
18Bits or 36Bits LVDS LCD interface
Ethernet
Duel Ethernet
Introduction
EP820 All-In-One EPIC Board User's Manual
®
915GM
3
