It defines continuous idle time before the system
1/2/4/6/8/10/2
entering the SUSPEND mode.
0/30/40
If any item defined in (J) is enabled and active, the
Min/1 Hr
SUSPEND timer will be reloaded.
HDD Power Down
If HDD activity is not detected for a specified length of time in this
field, the hard disk drive will be powered down while other devices
remain active.
Soft-Off by PWR-BTTN
This option only works with systems using an ATX power supply. It
also allows users to define which type of soft power OFF sequence
the system will follow. The default value is "Instant-Off".
This option follows the conventional manner of system
performance when turning the power to OFF. Instant-Off
Instant-Off
is a software power OFF sequence requiring the power
supply button is switched to OFF.
Upon the system's turning OFF through the power
switch, this option will delay the complete system power
OFF sequence approximately 4 seconds. Within this
Delay 4 Sec.
delay period, the system will temporarily enter into the
Suspend Mode enabling you to restart the system at
once.
CPU THRM-Throttling
This item allows you to set up the CPU thermal throttling rate that
you can reduce the CPU speed when it reaches the preset highest
temperature.
Wake-Up by PCI card
If enable this item, the system can automatically resume when the
PCI Modem or PCI LAN card receives an incoming call.
PowerOn by Ring
This option allows the system to resume or wake up upon detecting
any ring signals coming from an installed modem. The default
value is "Enabled".
Wake Up On LAN
When this option is enabled, a wake up event will awaken the
system from the power-down state.
Award BIOS Utility
