This item specifies the power saving modes for ACPI function. If
your operating system supports ACPI, such as Windows 98SE,
Windows ME and Windows 2000, you can choose to enter the
Standby mode in S1 (POS) or S3 (STR) fashion through the setting
of this field. Options are:
[S1 (POS)] The S1 sleep mode is a low power state. In this
state, no system context is lost (CPU or chipset) and
hardware maintains all system contexts.
[S3 (STR)] The S3 sleep mode is a lower power state where
the information of system configuration and open
applications/files is saved to main memory that remains
powered while most other hardware components turn off to
save energy. The information stored in memory will be used
to restore the system when a "wake up" event occurs.
Power Management
This option allows you to select the type (or degree) of power
saving for Doze, Standby, and Suspend modes. The table below
describes each power management mode:
It is maximum power savings, only available for SL CPUs.
Max Saving
The inactivity period is 1 minute in each mode.
It sets each mode. Select time-out periods in the PM
User Define
Timers section.
It is minimum power savings. The inactivity period is 1
Min Saving
hour in each mode (except the hard drive).
Disabled Default value
PM Control by APM
If Advanced Power Management (APM) is installed in your system,
the selection of Yes will give better power savings. The default
value is "Yes".
System BIOS will ignore APM when power is managing the
No
system
The System BIOS will wait for APM's prompt before it enters
any PM mode (i.e., DOZE, STANDBY or SUSPEND).
Yes Note: If APM is installed or there is a task running, even when
the timer has timed out, the APM will not prompt the BIOS to
put the system into any power saving mode
NOTE: If APM is not installed, this option doesn't work.
