  • Page 1 IMB200 ® Intel PentiumD/Pentium4/Celeron D Industrial ATX Motherboard User’s Manual...

  • Page 2: Disclaimers

    Disclaimers The information in this manual has been carefully checked and is believed to be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. AXIOMTEK assumes no responsibility for any inaccuracies that may be contained in this document.

  • Page 3: Esd Precautions

    Award is a trademark of Award Software, Inc. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. Intel Pentium D, Pentium4, Celeron D is trademarks of Intel Corporation. Other brand names and trademarks are the properties and registered brands of their respective owners.

  • Page 4: Table Of Contents

    T a b l e o f C o n t e n t s Disclaimers ... ii ESD Precautions ... iii Chapter 1 Introduction... 1 General Description ... 1 Specifications ... 2 Utilities Supported... 3 Ordering information ... 3 Board Dimensions ...
  • Page 5 4.11 Audio Jack (Line-in/Line-Out/MIC)-CN3... 27 4.12 ATX12V CPU Power Connector: CN14 ... 27 4.13 Serial ATA Connectors-CN28/CN29 ... 28 4.14 PS/2 Keyboard/Mouse connector-CN4 ... 29 4.15 Digital I/O Connector-CN38 ... 29 4.16 CD/In Connector-CN9 ... 30 4.17 CPU/System FAN Connector-CN23/CN24 ... 31 Chapter 5 Installing VGA driver ...
  • Page 6 On Board Device IRQ Routing ... 69 AppendixC Detailed memory Addess Mapping ... 70 AppendixD I/O Shield... 71...

  • Page 7: Chapter 1 Introduction

    The IMB200 supports LGA775-pin Intel® Pentium® D (Intel Dual-Core) processor up to 3.6GHz with a 533/800MHz front side bus (FSB), and features an Intel® 865G + ICH*5 chipset. With Intel dual-core processing technology, the IMB200 provides the excellent performance to handle multitasking and to run multiple applications simultaneously.

  • Page 8: Specifications

    IMB200 LGA775 ATX MB User Manual Specifications ® Processor: Intel Pentium D/Pentium4/Celeron ® North Bridge: Intel 82865G ® South Bridge: Intel 82801EB(ICH5) CPU Socket: LGA775 FSB: 533/800 Mhz L2 Cache: Integrated in CPU(Depend on CPU) BIOS: Phoenix Award BIOS Rev.6.00...

  • Page 9: Utilities Supported

    NOTE: Specifications are subject to change without notice. Utilities Supported ® Intel 865G Utility and Drivers Ethernet Utility and Drivers VGA Drivers Audio Driver Ordering information Model number Description IMB200VGE Intel547GI/Intel82562ET LAN IMB200VG Intel547GI Introduction IMB200 LGA775 ATX MB User Manual degrees(Depends on CPU)

  • Page 10: Board Dimensions

    IMB200 LGA775 ATX MB User Manual Board Dimensions Introduction...

  • Page 11: Chapter 2 Jumpers And Connectors

    IMB200 LGA775 ATX MB User Manual Chapter 2 Jumpers and Connectors Board Layout Jumpers and Connectors...

  • Page 12: Jumper Settings

    IMB200 LGA775 ATX MB User Manual Jumper Settings Followed as below detailed description for Jumper setting and installed the IMB200 for your application Jumper Default Setting Watchdog Trigger Mode : Disable Com 1 RS232/422/485 Setting CMOS Clear Jumper : Normal...

  • Page 13: Com1 Rs232/422/485 Settings: Jp4, Jp5,Jp6

    IMB200 LGA775 ATX MB User Manual 2.2.2 COM1 RS232/422/485 Settings: JP4, JP5, JP6 COM1 RS-232 Short 3-5,4-6 (Default) RS-422 Short 1-3,2-4 RS-485 Short 1-3,2-4 2.2.3 Clear CMOS Setting: JP7 Clear CMOS 2.2.4 CF Master/Slave Setting: JP8 Jumpers and Connectors Short 1-2,7-8...

  • Page 14: Cf Power Setting: Jp9

    IMB200 LGA775 ATX MB User Manual 2.2.5 CF Power Setting: JP9 Options Settings 3.3V 1-2(Default) Jumpers and Connectors...

  • Page 15: Connectors

    IMB200 LGA775 ATX MB User Manual 2.3 Connectors The following table lists the function of each connector on IMB200. Connectors Label General Output CN37 Connector Printer Port Connector COM1 COM2 CN33 COM3 CN25 COM4 CN27 USB Port 1, 2 Connector...
  • Page 16 IMB200 LGA775 ATX MB User Manual Connectors Label ATX Power Connector CN31 LGA775 CPU Socket DIO Connector CN38 Connectors Label PCI Slot PCI1~ AGP Slot AGP8 Jumpers and Connectors...

  • Page 17: Chapter 3 Installation

    IMB200 LGA775 ATX MB User Manual Chapter 3 Installation Before installing the processor, Please pay more attention on Intel website and obtained more information http://www.intel.com. 3.1 CPU Installation The LGA775 processor socket comes with a lever to protect the processor. Please pay more attention as below. Follow the pictures and place the processor into CPU socket.
  • Page 18 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 19 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 20 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 21 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 22 IMB200 LGA775 ATX MB User Manual Installation...
  • Page 23 IMB200 LGA775 ATX MB User Manual Installation...

  • Page 24: Installing Atx Power Supply

    Dual Channel DDR 266/333/400 memory and support the maximum memory capacity could up to 4GB. If you want to know what is difference between DDR and DDR2.See below picture PS: IMB200 only support Un-Buffered DIMM and could not support ECC/Registered DIMM Installation...
  • Page 25 IMB200 LGA775 ATX MB User Manual Installation...

  • Page 26: Chapter 4 Hardware Description

    IMB200 LGA775 ATX MB User Manual Chapter 4 Hardware Description 4.1 General Output Connector: CN37 Power LED Pins 1, 3, 5, 7 connect the system power LED indicator to its respective switch on the case. Pin 1 is +, and pin 5 is assigned as -.Pin 7 is defined as NC...

  • Page 27: Enhane Ide1/Ide2 Connecotor-Ide1 And Ide2

    IMB200 LGA775 ATX MB User Manual 4.2 Enhance IDE1/IDE2 connecotor-IDE1 and IDE2 IMB200 provided two IDE Port and support the maximum IDE devices could up to four Description Reset # Data 8 Data 5 Data 11 Data 2 Data 14...

  • Page 28: Display Interface-Cn1

    IMB200 LGA775 ATX MB User Manual 4.3 Display interface-CN1 The GMCH provides interfaces to a progressive scan analog monitor and DVO can drive a variety of DVOdevices• The GMCH has an integrated 350 MHz RAMDAC that can directly drive a progressive scan analog monitor up to a resolution of 2048x1536 at 75 Hz.

  • Page 29: Parallel Port Connector

    IMB200 LGA775 ATX MB User Manual Motor enable A # Motor enable B # Write data # Write protect # Disk change # 4.5 Parallel Port Connector Standard mode: IBM PC/XT, PC/AT and PS/2 compatible with bi-directional parallel port Enhanced mode: Enhance parallel port (EPP) compatible with EPP 1.7 and EPP...

  • Page 30: Com1 Port Connector-Cn2

    IMB200 LGA775 ATX MB User Manual Strobe # Data 0 Data 1 Data 2 Data 3 Data 4 Data 5 Data 6 Data 7 Acknowledge # Busy Paper Empty # Printer Select 4.6 COM1 Port Connector-CN2 *CN2 is DB-9 Connector* and belong to Jumper...

  • Page 31: Com2/3/4 Port Connector-Cn25/Cn27/Cn33 Support Rs232

    IMB200 LGA775 ATX MB User Manual 4.7 COM2/3/4 Port Connector- CN25/CN27/CN33 support RS232 4.8 USB and Gigabit LAN RJ-45 Connector- Hardware Description...

  • Page 32: Usb And 10/100Mb Lan Rj-45 Connector-Cn7

    IMB200 LGA775 ATX MB User Manual 4.9 USB and 10/100Mb LAN RJ-45 Connector-CN7 4.10 USB Connector by pin header-CN30 Hardware Description...

  • Page 33: Audio Jack (Line-In/Line-Out/Mic)-Cn3

    IMB200 LGA775 ATX MB User Manual G ND AG ND G ND 4.11 Audio Jack (Line-in/Line-Out/MIC)-CN3 4.12 ATX12V CPU Power Connector: CN14 This connector connected to an ATX12V power supply and used for CPU Core Voltage. Important Note: Make sure your ATX12V power supply can provide 16A on the +12V lead and at least 1A on the +5V standby lead (+5VSB).

  • Page 34: Serial Ata Connectors-Cn28/Cn29

    IMB200 LGA775 ATX MB User Manual minimum recommended wattage is 250W or 300W for a fully configured system. The system may become unstable and may experience difficulty powering up if the power supply is inadequate. 4.13 Serial ATA Connectors-CN28/CN29 Hardware Description...

  • Page 35: Ps/2 Keyboard/Mouse Connector-Cn4

    IMB200 LGA775 ATX MB User Manual 4.14 PS/2 Keyboard/Mouse connector-CN4 4.15 Digital I/O Connector-CN38 Hardware Description...

  • Page 36: Cd/In Connector-Cn9

    IMB200 LGA775 ATX MB User Manual 4.16 CD/In Connector-CN9 Hardware Description...

  • Page 37: Cpu/System Fan Connector-Cn23/Cn24

    IMB200 LGA775 ATX MB User Manual 4.17 CPU/System FAN Connector- CN23/CN24 Hardware Description...

  • Page 38: Chapter 5 Installing Vga Driver

    IMB200 LGA775 ATX MB User Manual Chapter 5 Installing VGA driver Introduction The GMCH provides interfaces to a progressive scan analog monitor. The GMCH has an integrated 350 MHz RAMDAC that can directly drive a progressive scan analog monitor up to a resolution of 2048x1536 at 75 Hz.
  • Page 39 IMB200 LGA775 ATX MB User Manual To install or upgrade the Intel 865G video driver: Run SETUP.EXE from the driver directory on your drivers Follow the onscreen directions to complete installation. There may be messages about the driver not having a digital signature, select Yes to all these message boxes.

  • Page 40: Windows Xp Vga Driver Installation

    IMB200 LGA775 ATX MB User Manual Windows XP VGA Driver Installation To install video support If you have installed retail Windows you need to install the video driver. The driver is contained in the \IMB200\Drivers\VGA subdirectory on the drivers CD.

  • Page 41: Chapter 6 Installing Lan Driver

    IMB200 LGA775 ATX MB User Manual Chapter 6 Installing LAN Driver Introduction IMB200 was built-in high performance Plug and Play Ethernet interface which is fully compliant with the IEEE 802.3 standard, and consisting of the RJ-45 connector Features 10/100/1000BASE-T Triple-speed MAC...

  • Page 42: Chapter 7 Award Bios Utility

    IMB200 BIOS Introduction The Award BIOS (Basic Input/Output System) installed in your computer system’s ROM supports Intel Celeron processors in a standard IBM-AT compatible I/O system. The BIOS provides critical low-level support for standard devices such as disk drives, serial and parallel ports. It also adds virus and password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system.
  • Page 43 We strongly recommend that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both Award and your system manufacturer to provide the absolute maximum performance and reliability. Award Bios Utility IMB200 LGA775 ATX MB User Manual...

  • Page 44: Standard Cmos Setup

    IMB200 LGA775 ATX MB User Manual Standard CMOS Setup “Standard CMOS Setup” allows you to record some basic hardware configurations in your computer system and set the system clock and error handling. If the motherboard is already installed in a working system, you will not need to select this option.
  • Page 45 HEADS number of heads PRECOMP write precom If there is no hard disk drive installed, select NONE and press <Enter>. Award Bios Utility IMB200 LGA775 ATX MB User Manual LANDZONE landing zone SECTORS number of sectors MODE HDD access mode...
  • Page 46 IMB200 LGA775 ATX MB User Manual Drive A type/Drive B type The category identifies the types of floppy disk drive A or drive B installed in the computer. None No floppy drive installed 360K, 5.25 in 5.25 inch PC-type standard drive; 360Kb capacity 1.2M, 5.25 in...

  • Page 47: Advanced Bios Features

    IMB200 LGA775 ATX MB User Manual Advanced BIOS Features This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 7.4.1 CPU Feature Clicks the cursor to this field and press <Enter>. The following screen will be appeared.
  • Page 48 IMB200 LGA775 ATX MB User Manual may not be identical to this one. Delay prior to Thermal This filed is used to select the time that would force the CPU to a 50% duty cycle when it exceeds us maximum...

  • Page 49: Hard Disk Boot Priority

    One of the key things this setting usually does when enabled is cause the POST to skip checking all of extended memory for errors. Award Bios Utility IMB200 LGA775 ATX MB User Manual...
  • Page 50 IMB200 LGA775 ATX MB User Manual Most people enable this setting to speed up the boot process, but you should realize that you do increase the chance of the POST missing an error if you use this. Fortunately (or unfortunately) the POST memory test is virtually useless to...
  • Page 51 This item can enable or disable the APIC (Advanced Programmable Interrupt. Controller). Due to compliance to PC2001 design guide, the system is able to run. In APIC mode. Enabling APIC mode will expand available IRQs Controller. Award Bios Utility IMB200 LGA775 ATX MB User Manual...

  • Page 52: Advanced Chipset Features

    IMB200 LGA775 ATX MB User Manual Advanced Chipset Features Since the features in this section are related to the chipset on the CPU board and are completely optimized, you are not recommended to change the default settings in this setup table unless you are well oriented with the chipset features.
  • Page 53 System Memory Frequency The Intel 865G Support Intel DDR 266/333/400.This setting could help you and setup the DRAM clock for DDR memory module. The default setting was...
  • Page 54 IMB200 LGA775 ATX MB User Manual cache will allow access to video BIOS addressed at C0000H To be cached if the cache controller is also enabled. The larger the range of the Cache RAM, the faster the video performance. Memory Hole At 15M-16M You can reserve this area of system memory for ISA adapter ROM.
  • Page 55 **On-Chip VGA Setting** On-Chip VGA This item allows to Disabled or enabled On-Board Frame Buffer Size This item allows adjusting the Frame Buffer Size Award Bios Utility IMB200 LGA775 ATX MB User Manual onboard VGA...

  • Page 56: Integrated Peripherals

    IMB200 LGA775 ATX MB User Manual Integrated Peripherals This option sets your hard disk configuration, mode and port. 7.6.1 On-Chip IDE Device Move the cursor to this field and press <Enter>. The following screen will be appeared. Award BIOS Utility...
  • Page 57 IMB200 LGA775 ATX MB User Manual On-Chip Primary PCI IDE This option could allow you to enable or disable the primary and secondary IDE controller, select Disabled if you want to add a Different hard drive controller. IDE Primary Master PIO...

  • Page 58: Onboard Device

    IMB200 LGA775 ATX MB User Manual This option could allow you to set up Master IDE interface from PIO mode0 to PIO Mode 4 IDE Primary Slave PIO This option could allow you to set up Slave IDE interface from PIO mode 0 to PIO Mode 4...
  • Page 59 AC97 Audio This option could helps to disable or enabled onboard Audio function The choice: Enabled, Disabled. Fast Ethernet Select Disabled could help to disable onboard Fast Ethernet controller Gigabit Ethernet Award Bios Utility IMB200 LGA775 ATX MB User Manual...

  • Page 60: Super Io Device

    IMB200 LGA775 ATX MB User Manual Select Disabled could help to disable onboard Gigabit Ethernet controller. 7.6.3 Super IO Device Move the cursor to this field and press < Enter >. The following Screen will be appeared. Onboard FDC Controller...
  • Page 61 This is used to select a DMA channel of the parallel port. 7.6.4 Onboard UART 3/4 Use the onboard UART. In this mode you should use the Picasso SDK UART-functions. The. Data will be set to the RS- 232 a connector Award Bios Utility IMB200 LGA775 ATX MB User Manual...

  • Page 62: Spread Spectrum

    IMB200 LGA775 ATX MB User Manual 7.6.5 Onboard UART 3/4 IRQ Use these BIOS setting could help to set up the IRQ for Onboard UART 7.6.6 Spread Spectrum Spread spectrum is a form of wireless communications in which the frequency of the transmitted signal is deliberately varied.

  • Page 63: Power Management Setup

    This field allows you select the type (or degree) of power saving By changing the length of idle time that elapses before the Suspend mode and HDD Power Down fields are activated. Award Bios Utility IMB200 LGA775 ATX MB User Manual...
  • Page 64 IMB200 LGA775 ATX MB User Manual Saving: Minimum power saving time for the Suspend Mode (1 hour) and HDD Power Down (15 min.) Max Saving: Maximum power saving time for the Suspend Mode and HDD Power Down =1 min. User Define: Allows you to set the power saving time in The “Suspend Mode “and “HDD Power Down “fields.
  • Page 65 KB/Mouse PWN After PWR-Fail This item specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are:. Off. Leaves the computer in the power off state. Award Bios Utility IMB200 LGA775 ATX MB User Manual...

  • Page 66: Pnp/Pci Configuration

    IMB200 LGA775 ATX MB User Manual PNP/PCI Configuration This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components.
  • Page 67 VGA cards, high-end hardware MPEG decoders etc. need to be able to look at the video card's VGA palette to determine what colors are currently in use. Enabling this feature turns on this palette "snoop Award Bios Utility IMB200 LGA775 ATX MB User Manual...

  • Page 68: Pc Health Status

    IMB200 LGA775 ATX MB User Manual PC Health Status This option configures the PCI bus system. All PCI bus systems on the system use INT#, thus all installed PCI cards must be set to this value. Current System1 Temperature. The current system power will be detected automatically.

  • Page 69: Frequency/Voltage Control

    This field is used to select the CPU’s frequency Auto Detect DIMM/PCI Clk Leave this field in its default setting. Do not alter this setting unless advised by an engineer or technician. Award Bios Utility IMB200 LGA775 ATX MB User Manual...

  • Page 70: Load Fail-Safe Default

    IMB200 LGA775 ATX MB User Manual 7.11 Load Fail-Safe Default When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N)? N Pressing “Y” loads the default values that are factory settings for optimal performance system operations 7.12 Load Optimized Default...
  • Page 71 IMB200 LGA775 ATX MB User Manual Set User Password: just can only enter but do not have the right to change the options of the setup menus. When you select this function, the following message will appear at the center of the screen to assist you in creating a password.

  • Page 72: Exit Setting

    IMB200 LGA775 ATX MB User Manual computer. You determine when the password is required within the BIOS Features Setup Menu and its Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup.
  • Page 73 IMB200 LGA775 ATX MB User Manual Pressing <Enter> on this item asks for confirmation: Quit without saving (Y/N)? Y This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your compute...

  • Page 74: Appendix A Watchdog Timer

    IMB200 LGA775 ATX MB User Manual A p p e n d i x A Watchdog Timer Please follow the below WDT process for setup the WDT function. Watchdog Timer...

  • Page 75: Appendix B Pci Irq Routing

    IMB200 LGA775 ATX MB User Manual A p p e n d i x B PCI IRQ Routing PICMG PCI IRQ Routing Device Slot PCI Slot 1 PCI Slot 2 PCI Slot 3 PCI Slot 4 PCI Slot 5 On Board Device IRQ Routing...
  • Page 76 IMB200 LGA775 ATX MB User Manual AppendixC Detailed memory Addess Mapping Detailed Memory Address Mapping...
  • Page 77 IMB200 LGA775 ATX MB User Manual AppendixD I/O Shield P/N was 728F2000100E I/O Shield...
