3.1

The EP820 Series supports Socket 478 for Intel

M/Celeron

M processors at FSB400/533MHz, which make your

system operated under Windows

The system performance depends on the microprocessor. Make sure

all correct settings are arranged for your installed microprocessor to

prevent the CPU from damages.

3.2

The EP820 Series uses Award Plug and Play BIOS with a single 4Mbit

Flash EPROM.

3.3

The EP820 Series industrial CPU card supports one 200-pin DDR2

SODIMM socket for a maximum memory of 1GB DDR SDRAMs. The

memory module can come in sizes of 64MB, 128MB, 256MB, 512MB

and 1GB.

Hardware Description

EP820 All-In-One EPIC Board User's Manual

C h a p t e r 3

Hardware Description

2000/XP and Linux environments.

Pentium
