Pin
Description
1
Digital Input 1(BIT7)
3
Digital Input 2(BIT6)
5
Digital Input 3(BIT5)
7
Digital Input 4(BIT4)
9
GND
Digital I/O
EP820 All-In-One EPIC Board User's Manual
Pin
Description
2
DigitalOutput 1(BIT3)
4
DigitalOutput 2(BIT2)
6
DigitalOutput 3(BIT1)
8
DigitalOutput 4(BIT0)
10 GND
CN10
73
