EP820 All-In-One EPIC Board User's Manual

2.3.1

CPU Type Select Jumper: JP1

Use this jumper to select the CPU type.

Description

CPU Type Select

This jumper is to select the voltage for LVDS1 interface.

Description

LVDS1 Voltage

Select

Function

Dothan A

(Default)

Dothan B/

Yonah

Function

3.3V (Default)

Jumper Setting

JP1

Jumper Setting

JP2

Jumpers and Connectors
