When the IR transmission is enabled, you can set up speeds
of reception (RxD) and transmission (TxD).
IR Transmission Delay
Enable or disable this item to decide if the IR transmission
delay function will be set or not while transferring to the
reception mode.
UAR2 Duplex Mode
The second serial port offers these infrared interface modes:
1. IrDA
2. ASKIR IrDA-compliant serial infrared port
3. Normalo (default value)
NOTE: The UART Mode Select will not appear on the menu
once you disable the setting of Onboard Serial Port
2.
Use IR Pins
Use this item to set up IR devices based on the IR pin
definitions.
Onboard Paralellel Port
This item allows you to determine the I/O address for
onboard parallel port. Options: 378/IRQ7, 278/IRQ5,
3BC/IRQ7 and Disabled.
Parallel Port Mode
Select an operating mode for the onboard parallel (printer)
port. Select Normal unless your hardware and software
require another mode in this field.
EPP Mode Select
Select EPP port type 1.7 or 1.9.
ECP Mode Use DMA
Select a DMA channel for the parallel port while using the
ECP mode.
PWRON After PWR-Fail
This item enables your computer to automatically restart or
return to its operating status.
Press <Esc> to return to the Integrated Peripherals page.
Onboard Lan Boot ROM
Use this item to enable or disable the Boot ROM function of the
onboard LAN chip when the system boots up.
Award BIOS Utility
